Features

Crossover Network

• Mounting: Easy-Mount Screw Terminals
• Attenuation Control: 7-Level Tweeter Attenuation
• Case Design: Sleek Crossover Case
• Grade: Professional Grade Network

Woofer

• Frame: Rigid Custom Cast Aluminum Frame
• Mounting: Shallow Mounting Design
• Magnet: High Grade Strontium Magnet
• Cooling: Optimized Air-Flow Design
• Voice Coil Type: Large Square-Wire Short Voice Coil
• Motor Technology: Linear Drive Technology
• Cone Material: Varnish Multi-Layer Cap & Cone
• Dustcap Detail: Kevlar Reinforced, Phase Integrated Dustcap

Tweeter

• Magnet Material: Ultra Low Distortion Magnet Design
• Application Type / Design Detail: External / Swivel Tweeter Mounting Kit
• Mounting Design: Shallow Mounting Design
• Tweeter Type: Bright, Crisp 1'' Ring Tweeter with Resonance Absorber

Specifications

General

• Sensitivity: 86dB /W(1m)
• Impedence: 3.6 Ohms
• Frequency Response: 70Hz - 27kHz

Dimensions

• Crossover Size (in): 4-9/16'' x 2-7/8'' x 1-1/4''
• Crossover Size (mm): 115.4mm x 73mm x 32mm
• Woofer Mounting Depth (in): 2-5/32''
• Woofer Mounting Depth (mm): 55mm
• Woofer Mounting Diameter (in): 4-19/32''
• Woofer Mounting Diameter (mm): 117mm
• Woofer Diameter (in): 5-1/4''
• Woofer Diameter (mm): 133.35mm
• Tweeter Mounting Depth (in): 3/4''
• Tweeter Mounting Depth (mm): 18.3mm
• Tweeter Mounting Diameter (in): 2''
• Tweeter Mounting Diameter (mm): 51mm

Power Handling

• Power Handling Capacity (Peak): 300 Watts
• Power Handling Capacity (RMS): 100 Watts
• CEA-2031 Power Rating: 100 Watts

Upgraded Design, Quality Sound Reproduction

Experience greater detail and impact of your music with the hybrid layered-pulp with mica coating woofer cone and new 1" ring tweeter. A new external network design with seven-level tweeter adjustment allows for precise tuning, while the hidden screw terminal gives a sleek appearance. Adjust the tuning of your speakers using the crossovers to individually perform fine adjustments of the tweeter level. Ultimately, get far more detail and bright and crisp sound reproduction for a great sounding, loud system.

Easy Installation

Installation is made fast and easy with a shallower mounting depth, and basket design. A 6x8” mounting adapter plate is also included for fitment, so this solution is versatile to fit in many vehicles (Only Available on SPR-17S and SPR-13S). Choose from multiple models of both components and coaxials to fit the needs of your car.



Better Balance & Staging
The coaxial models feature a 1" swivel ring tweeter to improve off-axis response in less than ideal installation locations. You can aim it by hand for best sound balance and staging, pointing at the optimum listening position.

Smooth High Frequency
Resonance Absorbers are used to ensure “focused” tonal playback, eliminating unwanted reverberating sound.

Accurate Tweeter Control
Ultra Low Distortion Magnet Design uses extra copper and large neodymium magnet is used to create accurate speaker control, ensuring low distortion and high tonal accuracy.


Fine-Tuned Multi-Layer Cone
New shape & cone materials are used in the Type-R series. The cone uses a combination of thick top-coated varnish, special fibers and glue, and rigorous pressure testing to ensure a lighter and strong material for smooth consistent performance.

Faithful to the Original Sound
The High-performance Linear Drive Motor structure has a large magnet that is almost as big as the voice coil diameter. Its dual radial magnet and twin gap combined with a square, edge-wound voice coil gives the diaphragm linear movement over a much greater range. This means the speaker is faithful to the input signal even during high excursion, for accurate musical reproduction and deep bass.

Superior Efficiency and Linearity

Alpine’s exclusive design allows wider music range playback, tonal and stable balance with greater excursion, and precise speaker movement for accurate music reproduction and deep bass.

Great Sound, High Power Handling
A large flat copper wounding on the woofer voice coil is used for high power handling and fluid movement during music playback. This contributes great sound and durable performance from the speaker.

Cut View

SPR-17S/-13S Woofer

SPR-17S/-13S Tweeter

SPR-17S/-13S Crossover
